    Pe Insulation Wire Spiral Binding Coil Ul21030 With ISO Certification

    Ask Lasest Price
    Brand Name : YANGDA
    Model Number : 21030
    Certification : UL
    Price : 1usd per meter
    Payment Terms : T/T
    Supply Ability : 1000000 per week
    Delivery Time : 10days
    • Product Details
    • Company Profile

    Pe Insulation Wire Spiral Binding Coil Ul21030 With ISO Certification

    Spiral Coiled Cable Ul21030 Pe Insulation Low Voltage Multi-Cores Pur Jacketed Tinned Copper Machinary Cable
    Product Description:
    1) Tinned, annealed,stranded or solid copper conductor.
    2) PP,PE or FR-PEinsulation.
    3) PUR jacketed.
    4) Rated temperature: 60°C,80°C.Rated voltage: 300volts
    5) Passes UL VW-1 & CSA FT1 vertical flame test.
    6)Executive Standard:UL758,UL1581,CSA22.2.
    Applications:
    External interconnection or internal wiring of electronic equipment.

    UL Style& CUL TypeCoresConductorInsulation
    Thickness
    Nom.DiaShield CoverageJacket ThicknessOverall
    Dimeter
    Conductor
    Resistance at 20℃
    AWGNo/mmmmmm%mmmmΩ/KM
    UL21030
    CUL
    (Stranded)
    2C307/0.1000.230.80>=650.763.60381.00
    287/0.1270.230.90>=650.763.90239.00
    267/0.160.231.00>=650.764.00150.00
    2411/0.160.231.10>=650.764.2094.20
    2217/0.160.231.30>=650.764.6059.40
    2021/0.1780.231.50>=650.765.0036.70
    1834/0.1780.231.80>=650.765.6023.20
    1626/0.250.232.00>=650.767.8014.60
    UL21030
    CUL
    (Stranded)
    3C307/0.1000.230.80>=650.765.50381.00
    287/0.1270.230.90>=650.765.70239.00
    267/0.160.231.00>=650.765.90150.00
    2411/0.160.231.10>=650.766.1094.20
    2217/0.160.231.30>=650.766.5059.40
    2021/0.1780.231.50>=650.767.0036.70
    1834/0.1780.231.80>=650.767.6023.20
    UL21030
    CUL
    (Stranded)
    4C307/0.1000.230.80>=650.765.70381.00
    287/0.1270.230.90>=650.765.90239.00
    267/0.160.231.00>=650.766.20150.00
    2411/0.160.231.10>=650.766.5094.20
    2217/0.160.231.30>=650.766.9059.40
    2021/0.1780.231.50>=650.767.4036.70
    UL21030
    CUL
    (Stranded)
    5C307/0.1000.230.80>=650.766.00381.00
    287/0.1270.230.90>=650.766.30239.00
    267/0.160.231.00>=650.766.40150.00
    2411/0.160.231.10>=650.766.8094.20
    2217/0.160.231.30>=650.767.4059.40
    UL21030
    CUL
    (Stranded)
    6C307/0.1000.230.80>=650.766.40381.00
    287/0.1270.230.90>=650.766.70239.00
    267/0.160.231.00>=650.767.00150.00
    2411/0.160.231.10>=650.767.3094.20


    Pe Insulation Wire Spiral Binding Coil Ul21030 With ISO Certification
